HE/AMH MOTORS High Efficiency
3-Phase; 50 or 60HZ; IP55

1.15 Service Factor (SF) • Available in 208-230/460V or 333/575V •
Frame Sizes 100 and above available in 575/990V version •
Frame Sizes 132 and above available in 460/776V version • TEFC •
Threaded Hole in Output Shaft is Standard • Squirrel Cage • Class F •
IP55 • IEC - CEI - UNEL MEC • CSA Approved •
Compliant with EPACT regulations and are NRCAN approved •
(UL Recognized are Class “B”)


TO CONVERT HP to KW, multiply by 0.746
Efficiencies Verified by UL
Safety Certified by CSA
1.15 Service Factor
Efficiencies Meet or Exceed all EPACT and CSA-C390 Requirements
Available in B3, B14 or B5 Mountings
True IEC Frames
230/460V Motors available in 9 leads
  - please enquire

2-Pole Motors     Wiring Diagrams

* Now available 315 frame sizes, please enquire
