| HE/AMH
MOTORS High Efficiency 3-Phase; 50 or 60HZ; IP55 |
| 1.15 Service
Factor (SF) • Available in 208-230/460V or 333/575V • Frame Sizes 100 and above available in 575/990V version • Frame Sizes 132 and above available in 460/776V version • TEFC • Threaded Hole in Output Shaft is Standard • Squirrel Cage • Class F • IP55 • IEC - CEI - UNEL MEC • CSA Approved • Compliant with EPACT regulations and are NRCAN approved • (UL Recognized are Class “B”) |
 |
 |
 |
| 4-Pole Motors Wiring Diagrams |
| * Now available 315 frame sizes, please enquire |
